Description
Frequency Range:
DC – 3000 MHz
Impedance:
50 Ohms nominal
Attenuation Value:
1 – 20 dB
Attenuation Accuracy:
± 0.75 dB maximum
VSWR: 1.40:1 maximum
Power Input:
1 Watt average
RF Connectors:
N Female / Female
Operating Temperature Range:
– 55°C to +100°C
