Description
Frequency Range: 450 – 500 MHz
Impedance: 50 Ohms nominal
Configuration: 4 way
Isolation: 25 dB typical, 20 dB minimum
Insertion Loss: ( above theoretical split ) 0.5 dB nominal
Amplitude Tracking: ± 0.3 dB maximum
Phase Tracking: ± 5° maximum
VSWR: 1.20:1 maximum
Power Input: 5 Watts average @ 25°C
RF Connectors: BNC Female
Operating Temperature Range: – 55°C to +85°C
